Flash
Removal Device
 |
|
Steady
Rest
|
|
Intermediate
Clamp (Steady Rest)
|
 |
This
is a device which removes curly shaped flash
produced at the time of friction welding. It is
2-axis servo control.
|
|
 |
This
is a device used after friction welding of lengthy work, and
it holds rotational swing in flash removal. |
|
 |
It
is a supporting aid to prevent distortion in friction
welding of lengthy work.
By replacing tip-jaw with roller-jaw, it can be used
as a steady rest in rotation of flash removal. |
 |
|
|
|
|
|
|
|
Oil
Cooler
|
|
Immersion
Heater
|
|
Extension
Table
|
 |
For
a stable operation, temperature management
of active oil and spindle lubricant is an
important factor.
Energy-saving inverter controlled oil cooler
has less change in temperature and controls
oil temperature. |
|
|
 |
To
prevent excess decline in oil temperature in cold area, an
immersion heater is installed and reduces initiating time
greatly.
|
|
 |
When
the material on the fixed side is long, extension table can
be attached at the end of the table.
|
|
|
|
|
|
|
|
|
Friction
Welding Effect Analog Output-terminal
|
|
Auto
Supply & Discharge Device
|
|
|
 |
It is a voltage
analog output-terminal to collect waveform data of each
parameter in friction welding. (BNC terminal)
Data logger is separately needed. |
|
 |
The
best combination suitable for your manufacturing field
is suggested such as auto supply and discharge device,
and material stock.
|
|
|
|
|
|
|
|
|
|
|
|
